The SuperT-AL solid carbide gun drills are very durable single fluted tools designed to drill extra deep holes on CNC machining centers without the need for specialized gun drill equipment. Drilling depths of over 75xD can be reached with one tool and without requiring peck cycles. The solid carbide construction from the shank to the cutting edge provides exceptional rigidity within the cut, best hole size tolerances and alignment accuracies. They are best suited for hole depths and hole sizes that are beyond the reach of the SuperV-T style spiral fluted drill. On CNC machining centers pilot hole drilling is required before any application of the SuperT-AL gun drill. These robust gun drills are for example applied for the machining of camshafts, crankshafts, drive shafts, injectors, and also in the medical and the food industry. SuperT-AL gun drills have a reinforced shank and we recommend using high quality shrink fit holders or hydraulic chucks to guarantee the highest concentricity and drilling efficiency.
Features:
- tool completely made of ultra-fine grained carbide grade
- specially developed geometry
- highly polished flutes
- shank with tapered MQL end (shank ≥ 6 mm)
- point coated with TiAlN nano
- head form G
Your Advantages:
- very robust and durable gun drill
- extra tight drilling tolerances
- from Ø1.0 to 16.0 mm as standard
- drilling up to 75xD with only one tool
- possible flute length until 580 mm
- suitable for almost any material
